155
MAINTENANCE
Rear gear case oil check
1. Place the vehicle on a level surface.
2. Remove the oil ller bolt
3
and check the oil level. The level
should be up to the brim of the hole. If the level is low, add
su󰀩cient oil to raise it to the specied level.
3. Install the oil ller bolt and tighten it to 18.4 ft-lb. (24 N•m).
Rear gear case oil change
1. Place the vehicle on a level surface.
2. Place an oil pan under the gear case to collect the used oil.
3. Remove the oil drain bolt
4
at the bottom of the gear case and
drain the oil.
4. Install the oil drain bolt and tighten it to 18.4 ft-lb. (24 N•m).
5. Add su󰀩cient oil to raise the level up to the brim of the hole.
6. Install the oil ller bolt and tighten it to 18.4 ft-lb. (24 N•m).
NOTE:
Approximate rear gear case oil capacity: 13.5 oz. (400mL)
3
4
