177
MAINTENANCE
Head light replacement
1. Access the headlight lamp:
• Remove the cover
2
3
from the headlight assembly
1
by
turning it counter-clockwise.
• Remove the cover to expose the headlight lamp.
2. Remove the headlight lamp lock spring.
3. Disconnect the failed bulb, pull it out, and replace it with a new
bulb.
4. Reinstall the bulb and lock spring into the headlight housing.
5. Reinstall the cover and turn it clockwise.
6. Test the head light and ensure it is working properly.
CAUTION
Hot surface. Touch the bulb only after it has cooled down. Do not
touch the bulb surface. Use gloves or other protection to keep oils
and dirt o the bulb.
NOTE:
The touring lamp and turning lamp (if equipped) assemblies are an
LED structure, which cannot be repaired if damaged or failed. Have
your dealer replace the entire assembly if an LED is damaged or
has failed.
2
1
3
