EF28 Electric Fireplace
10010019



Remove Screws
FP1745
Figure 6: Remove Trim



Remove Screws
Remove Screws
FP1746
Figure 7: Remove Front Cover, Brackets and
Diffusing Screen



Flame Blower
FP1773
Figure 9: Flame Blower and Rocker Switch Access
(Remove screws shown in Figure 8)




Remove Screws
FP1772
Ribbon Effect
Fan Heater
Figure 8: Fan Heater, Flame Blower,
Ribbon Effect and Circuit Board Access
Remove Screws
Circuit Board
