CFM HEF22 - Replacement Parts

13
10008388
11
305mm [12"]
216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS}
216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS)
1
2
3
4
5
6
7a
8
9
12
13
14
10
16
7b
CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time,
without notice.
HEF22/26/33 Electric Fireplace
Ref. Description HEF22 HEF26 HEF33
1. Logset 10006656 10006711 10006532/10008135 (alt.)
2. Ember Lava Rock 10008060 10008059 10006526
3. Circuit Board 10007870 10007870 10007870
4. Refractory Right Side n/a 10007877 10008013
5. Refractory Left Side n/a 10007877 10008015
