81
To Change the Coolant
1. Coolant drain bolt
1. Radiator cap
1
With vehicle on a level surface and engine
cold, proceed as follows:
1. Place an container under the engine to col-
lect the used oil.
2. Remove the coolant drain plug #1.
3. Remove the radiator pressure cap, along
with the coolant reservoir cap.
WARNING
In order to avoid potential burns, do not re-
move the pressure cap or loosen the coolant
drain plug if the engine is hot.
4. Drain the coolant in coolant reservoir.
5. If the drain plug washer is worn out, re-
place it with a new one.
6. Torque the drain plug to specification.
NOTE
Coolant drain plug tightening torque: 10 N·m
7. Install the coolant reservoir hose.
8. Add recommended coolant to proper level.
1
