Page. 25 of 63
3.2.1 The solar kit
A new mixing valve designed to be integrated in the prefitting kit.
This device allows to reduced the hot temperature coming from a
solar source to ensure the maximum comfort for the client and
the complete protection for the boiler.
3.2.2 Hydraulic connections cover
To finalize the installation with a best aesthetic, it is possible to install the hydraulic connections cover.
Cold water
(FR/BE market)
Cold water
(no FR/BE
market)
Mixed water
(Toward the
boiler
Hot water
(solar or other
source)
Kit solar mixing valve motor
with solar clip in
As accessory
