51
#
Appendix IIAppendix II
Appendix IIAppendix II
Appendix II
Quick Connector and Jumper ReferenceQuick Connector and Jumper Reference
Quick Connector and Jumper ReferenceQuick Connector and Jumper Reference
Quick Connector and Jumper Reference
V.1
SeePU (Jumper free CPU installation) setting table
CPU Type
CPU Speed
External Clock
Frequency
Ratio
Internal Clock
Pentium II
processor
66
3.5 233
4 266
4.5 300
5 333
100
3.5 350
4 400
45 450
IDE #1
IDE #2
Switching power module
FLOPPY
Power supply conn.
System BIOS
ISA1
PCI1
PCI2
PCI3
CN3
1
AGP
port
Intel
82443BX
PAC
USB x 2
PS/2 Mouse
& K/B Conn.
+
Battery
COM2
Printer
COM1
DIMM1,2,3
Line-out
Line-in
Mic-in
Audio
Chip
AC'97
Chip
Printer
COM2
COM1
Game
USB2
USB1
K/B
Mouse
PCB
Back Panel I/O Connector
JP1
CN9
1
1
JP2
1
+
CN5
JP8
1
FAN1
JP3
+
CN8
1
1
1
CN4
FAN2
BX-mATX-AUDIO-0.1BX-mATX-AUDIO-0.1
BX-mATX-AUDIO-0.1BX-mATX-AUDIO-0.1
BX-mATX-AUDIO-0.1
CN3: Infrared connector
CN5:WOL (Wake-on-LAN) Conn.
CN8: Front panel connector set
CN9:Creative's SB-LINK
Sound connector
FAN1/FAN2: CPU/System cooling
fan connector
JP1: CD-ROM audio in
JP2: I
2
S connector
JP3: External clock frequency jumper
Short: Determined by CPU
Open: Always 100MHz
JP8: Clear CMOS data jumper
1~2 : Normal (default)
2~3 : Clear CMOS data
SERIAL
IRQ
(PC/PC I)
GNT#
(PC/PCI)
REQ#
GND
1
