Challenge Xtreme XSZ40 Assembly Manual

1918
Customer Helpline 0845 450 5299
www.gardenservicecentre.co.uk
Customer Helpline 0845 450 5299
www.gardenservicecentre.co.uk
Troubleshooting Technical Data
Technical Data Table
Property Value
Engine type Single cylinder 4-stroke
Engine displacement 149.3cc
Engine max. power 2.1kW / 3600 rpm
Engine speed 2900rpm
Cutting width 40cm
Grass bag capacity 45L
Ignition T.C.I
Fuel tank capacity 0.8L
Oil tank capacity 0.6L
Sound pressure level 85 dB(A)
Sound power level 96 dB(A)
Vibration 3.7m/s
2
Spark type QJ19LM
Net weight 23kg
General Troubleshooting
CAUTION! Always switch off the engine and pull the ignition cable before starting any inspection
or adjustment work.
CAUTION! If, after making an adjustment or repair to the engine, you let it run for a few minutes,
remember that the exhaust and other parts will get hot. Thus, do not touch parts that emanate
heat, as these may burn you.
The following table provides solutions to common problems encountered with the lawnmower.
Fault Possible Cause Solution
Loud while running,
machine vibrates heavily
- Screws are loose
- Blade fasteners are loose
- Blade is unbalanced
- Check screws
- Check blade fasteners
- Replace blade
Engine does not start - start/stop bar not pressed
- Primer bulb is empty
- Spark plug is defective
- Fuel tank is empty
- Engine may be ooded
- Press start/stop bar
- Press primer bulb 3~5 times.
- Replace spark plug
- Rell with fuel
- remove plug and dry
Engine runs unsteadily - Air lter is soiled
- Spark plug is soiled
- Clean the air lter
- Clean the spark plug
Uneven mowing results - Blade is blunt
- Cutting height is too low
- Sharpen the blade
- Set correct height
Unsatisfactory bagging of
the grass
- Cutting height is too low
- Blade is worn
- grass bag is clogged
- Set correct height
- Replace the blade
- Empty the grass bag
Disposal
Disposal Instructions
The lawnmower and its accessories are made of various recyclable materials. Dispose of the
lawnmower in accordance with your local recycling regulations.
