GENERAL INFORMATION - A-5
79019435B
SPECIFICATIONS
1417
Mech.-4WD
1417
HST-4WD
1423/ST25/MT2
25
HST-4WD
1423/ST25/
MT225
Mech. 4WD
Dimensions (with ag-tires)
Front 5-12 5-12 5.00-12 5.00-12 Tire size
Rear 8-16 8-16 9.5–16 9.5-16
Overall length 254.5 (100.2”) 254.5 (100.2”) 268.0 (105.5”) 268 (105.5”)
Overall width 100.0 (39.4”) 100.0 (39.4”) 104.0 (41”) 104.0 (41”)
Overall height
(at steering wheel)
128.0 (50.0”) 128.0 (50.0”) 130.0 (52”) 130.0 (52”)
Wheel base 142.5 (56.1”) 142.5 (56.1”) 152.0 (59.8”) 152.0 (59.8”)
Front 75.0 (29.5”) 75.0 (29.5”) 75.0 (29.5”) 75.0 (29.5) Wheel tread
Rear 77.0/95.0
(30.3/37.4”)
77.0/95.0
(30.3/37.4”)
80.0/91.0
(31.5/35.8”)
80.0/91.0
(31.5/35.8”)
Minimum ground clearance
(under-rear-axle bottom)
25.5 (9.6”) 25.5 (9.6”) 28.0 (11.0”) 28.0 (11.0”)
Minimum turning radius:
with braking
[without] (m)
2.1 (80.7”)
[2.4] (94.5”)
2.1 (80.7”)
[2.4] (94.5”)
2.1 (80.7”
2.4 (94.5”)
2.1 (80.7”)
2.4 (94.5”)
Weight (with fuel, oil & coolant) 605 (1334 lbs) 630 (1390 lbs) 680 (1499 lbs) 650 (1433 lbs)
Km/hr (mph)
Range Main
shift
1 1.17 (.73) 1.27 (.79)
2 2.11 (1.31) 0-7.93 (4.93) 0-9.30 (5.80) 2.29 (1.42)
3 3.48 (2.16) 3.77 (2.34)
L
R 1.90 (1.18) 0-5.60 (0-3.48) 0-7.00 (0-4.35) 2.06 (1.28)
1 5.86 (3.64) 6.36 (3.95)
2 10.60 (6.59) 0-18.5 (0-11.5) 0-21.61(0-13.40) 11.50 (7.15)
3 17.40 (10.81) 18.90 (11.74)
Traveling
Speed
H
R 9.50 (5.9) 0-13.0 (0-8.08) 0-16.2 (0-10.0) 10.32 (6.40)
