Challenger MT738 - Fuel Filter; Separator Filter; Engine Oil Filter; Belt Routing

1.3.12 Fuel fil
ter
Fuel fil
ter
The decal is located on the fuel fil
ter.
1.3.13 Separator fil
ter
Separator fil
ter
The decal is located on the fuel water separator
fil
ter.
1.3.14 Engine oil fil
ter
Engine oil fil
ter
Change the engine oil fil
ters, as necessary. See the
maintenance schedule for the service intervals.
Discard the used filters correctly.
Related Links
Maintenance schedule page 41
8
1.3.15 Belt routing
Belt routing
Original art: /o/More/ST4/belt routing 605403D1-1-AC442-.pdf
TRHJA0110114201
Inspect the belts. Replace the belts if they are worn.
R
eplace the belt if it is cut or penetrated by a foreign
object.
GUID-A5842CB1-21CF-4B58-9B1B-7F82A6DF6522 [V1]
GUID-66D86DF7-6153-4B84-BAF0-B91AE8546CCF [V1]
GUID-FD8F5ABA-6777-4E76-A4FC-B5E060EBB4C1 [V1]
GUID-97071572-2B17-4AC5-9291-58715896B0BB [V2]
1. Safety
Rubber Track Tractor 37
589607D1G
