Challenger MT875C

79033095 C Rev. 02-15
Engine Component
FIG. 25: Disconnect battery at battery disconnect switch.
Rotate and remove key (1) to disconnect the battery
power.
FIG. 26: Remove fanblast guard.
Remove four bolts (1) and remove fanblast guard (2). The
weight of the fanblast guard is approximately 58 kg (128
lb).
FIG. 27: Drain engine coolant.
Place approved container under drain line (1). Turn valve
(2) counter clockwise to open. Drain engine coolant into
an approved container for storage or disposal. When
coolant is finished draining turn valve (2) clockwise to
close.
FIG. 28: Remove hood.
Remove hood (1). Refer to Removal and Installation -
Hood - Removal.
FIG. 25
1
N012206002
FIG. 26
P100506002
1
1
2
FIG. 27
2
1
N012606002
FIG. 28
P100506003
1
