17
ITEM PART NO. DESCRIPTION QUANTITY
M Motor 1111111111111111
36 160B0083 Relay 115V 1111
160B0084 Relay 230V 1111
37 1C4198 PCB 1 Phase 1 1 1 1 1 1 1 1
1C4197 PCB 3 Phase 1 1 1 1 1 1 1 1
38 160B0073-01 Overload 1-1.6 A* 1
160B0073-02 Overload 1.6-2.5A* 1
160B0073-03 Overload 2.5 - 4A* 1 1
39 204C0122-08 Transformer 115V 1111
204C0122-09 Transformer 230V 1 1 1 1 1 1 1 1
204C0122-07 Transformer 460V 1111
40 180B0159-0 Overload 3.5A 1
180B0159-1 Overload 5A 1
180B0159-2 Overload 7A 1 1
180B0159-3 Overload 8A 1
180B0159-4 Overload 10A 1
180B0159-5 Overload 15A 1
180B0159-9 Overload 12A 1
41 29A0132 Relay Clip 1 1 1 1 1 1 1 1
42 1B4048 Radio Cntrl Harness 1111111111111111
DESCRIPTION
MOTOR P/N
1/3 HP, 115V, 1 PHASE
123D0121
1/3 HP, 230V, 1 PHASE
123D0121
1/3 HP, 230V, 3 PHASE
123D0117
1/3 HP, 460V, 3 PHASE
123D0117
1/2 HP, 115V, 1 PHASE
123D0122
1/2 HP, 230V, 1 PHASE
123D0122
1/2 HP, 230V, 3 PHASE
123D0118
1/2 HP, 460V, 3 PHASE
123D0118
3/4 HP, 115V, 1 PHASE
123D0123
3/4 HP, 230V, 1 PHASE
123D0123
3/4 HP, 230V, 3 PHASE
123D0119
3/4 HP, 460V, 3 PHASE
123D0119
1 HP, 115V, 1 PHASE
123D0124
1 HP, 230V, 1 PHASE
123D0124
1 HP, 230V, 3 PHASE
123D0120
1 HP, 460V, 3 PHASE
123D0120
REMARKS: *Overload to be set at 115% maximum of motors rated current.
ELECTRICAL BOX PARTS LIST
FOR HT & HJ SERIES
ITEM
NO. PART NO. QTY DESCRIPTION
1 1B3727 1 Terminal Assy. 3-Lug
2 41K4304 1 Switch Bracket Assy. (Aux. & Sensing)
3 1B3796 1 Ltd. Shaft-Sprocket Assy.
4 1B3938 1 Cover & Hinge Assy.
5 1C3937 1 Electric Box Assy.
6 1D4017 1 Wire Harness
7 11A012 1 Flanged Sleeve Bearing
8 41K4303 1 Limit Bracket (Adj.) Kit
10 1B4062 1 Motor Cable Assy.
11 41K4305 1 PCB Holder Assy. Kit
12 31A388 1 Dome Plug
13 203A177 1 Terminal Strip 3 Lug
14 132A2011 1 Label - Class 2 NEC Circuit
15 132B1931 1 Control Wiring Label
16 132B1930 1 Label - Power Wiring
17 133A182 2 Limit Nut 1/2"
18 216A10 7 Washer #6 Internal Lock
19 157A84 4 Rivet
20 158A49 1 Retaining Ring 3/8
21 216A43 4 Washer #4 Internal Lock
22 160C86 1 Reversing Contactor
23 171A220 1 Screw #8F 1/2 SL Hex Green
24 171A311 4 S.T. SCR #8TF 3/8" Hex/Washer
25 216A140 6 Washer #8 Lock-Split
26 171A337 4 Machine Screw 8-32 x 1/2" Hex
27 171A339 2 Machine Screw 8-32 x 3/4" Sl. Pan
28 171A386 7 Screw 6-32 x 1/2" - Hex Head
29 171A411 4 Screw 4/40 x 1-1/2" Pan Head
30 216A149 1 Washer #8 Terminal Cup
31 216A184 2 Thrust Washer
32 216A191 1 Washer, Spring Curved
33 183B139 1 DIN Rail - 4-3/4"
34 184A109 4 Spacer - Stand Off - Round
35 184A112 2 PCB Stand Off
43 180B133 2 Limit Switch
