REPAIR PARTS FOR MODEL HT
19
ITEM #7 ITEM #11
Door Chain #41 Chain
Height Rail Qty Assembly Qty Master Link Qty Spacer Kit Qty
8 Ft. 183C0137 2 1A4026 1 109A0021 2 1A4005 2
10 183C0137-1 2 1A4027 1 109A0021 2 1A4005 2
12 183C0137-2 2 1A4028 1 109A0021 2 1A4005 2
14 183C0137-3 2 1A4029 1 109A0021 2 1A4005 3
16 183C0138 2 1A4030 1 109A0021 2 1A4005 3
18 183C0138-1 2 1A4031 1 109A0021 2 1A4005 3
20 183C0138-2 2 1A4032 1 109A0021 2 1A4005 4
22 183C0138-3 2 1A4033 1 109A0021 2 1A4005 4
ITEM #7 ITEM #11
Door Chain #48 Chain 1 Set
Height Rail Qty Assembly Qty Master Link Qty Spacer Kit Qty
8 Ft. 183C0137 2 1A3881 1 1A0995 1 1A4004 2
10 183C0137-1 2 1A3882 1 1A0995 1 1A4004 2
12 183C0137-2 2 1A3883 1 1A0995 1 1A4004 2
14 183C0137-3 2 1A3884 1 1A0995 1 1A4004 3
16 183C0138 2 1A3996 1 1A0995 1 1A4004 3
18 183C0138-1 2 1A3997 1 1A0995 1 1A4004 3
20 183C0138-2 2 1A3998 1 1A0995 1 1A4004 4
22 183C0138-3 2 1A3999 1 1A0995 1 1A4004 4
RAIL - CHAIN ASSEMBLY - SPACER KIT
for #48 Chain
RAIL - CHAIN ASSEMBLY - SPACER KIT
for #41 Chain
ITEM
NO. PART NO. QTY DESCRIPTION
1 1 Electrical Box Assy. (See detail)
2 1B4062 1 Motor Cable Assy.
3 Motor 1 See Chart
4 1C3972 1 Motor Plate Assy.
5 1A3971 1 Chain Assy. (49 Pitches)
6 81C151 1 Sprocket-Hub Assy. 13-3/4
7 See Chart 2 L-Rail
8 1B4001 1 Trolley Assy.
9 1C3992 1 1 Bracket Assy., #48 Chain
1C3993 1 1 Bracket Assy., #41 Chain
10 1C3692-2 1 Shaft Assy. - Pulley
11 See Chart Varies Spacer Kit
12 144C38 1 Pulley 8" - 5L
13 1C3688 1 Shaft Assy. - Intermediate
14 1C3689 1 Shaft Assy. - Output - #48
1C4023 1 Shaft Assy. - Output - #41
15 41K4301 1 Clutch Assy. Kit
16 20B9 1 V-Belt 41" - 5L
17 144B37 1 Pulley 2-1/2" - 5L
18 59D48-2 1 Frame Right Side
59D48-3 1 Frame Left Side
19 184B97 4 Spacer
20 41K4300 1 Ball Bearing 3/4" I.D. Kit
21 1A3741 2 Chain Assy. (41 Pitches) #48 Chain
22 41K4302 1 Header Brk. Assy.
23 41K4306 2 Oil Lite Brg. 3/4" I.D. Kit
