Specifications
Input voltage
Max. pulling force
Nominal torque
Standby consumption
Input accessories
Max. door weight
230-240 V 50 Hz
600 N
5.0 Nm
0,8 Watt
24 V / 300 mA
90 kg
Motor
Type worm gear type
Voltage 24 V
Noise level 55 dB
Drive mechanism
Length of travel 2.63 m
Speed 10 cm/sec
Lighting LED 1W
Safety
Electronically automatic force adjustment
Electrically thermal fuse in transformer
Limit switch adjustment manually
Dimensions
Length (overall) 3.14 m
Required clearance height min. 35 mm
Suspended weight 10 kg
Radio receiver
Memory 16 remote controls
Operating frequency 433 MHz, 868 MHz
Battery 3 V, type CR2032 (10A20-WH)
Accessory (optional)
1.
2.
TX4EV/S
3.
128EV
4.
747EV
5.
75EV
6.
770EV
4-channel remote control
2-channell wireless wall control
keypad
illuminated push button
safety photocells
(Door reverses automatically without touching an
obstacle)
EQL01EV external quick release
15
17
Declaration of conformity
18
Declaration of conformity
The listed automatic garage door opener corre-
sponds to the applicable sections of the standards
EN 55014-1 (2006), EN 55014-2 (2008), EN 61000-
4-2 (2009), EN 61000-4-3 (2008), EN 61000-4-4
(2004), EN 61000-4-5 (2007), EN 61000-4-6 (2009),
EN 61000-4-11 (2004), EN 62233 (2008), EN
300220-1 (V2.3.1), EN 300220-2 (V2.1.2), EN
60335-1 (2010), EN 60335-2-95 (2004) in accor-
dance with the provisions and all amendments to the
European Directives 2004/108/EC, 2006/95/EC,
2006/42/EC and 1999/5/EC.
Model:..............................................................LM55
S./N.:.............................xxxxx000001 - xxxxx99999
ManufacturerChamberlain GmbH
Alfred-Nobel-Str. 4
D-66793 Saarwellingen
All technical archive data for the opener and the
associated accessories are kept safe by Chamber-
lain GmbH and will be provided to the authorities
on request if required.
Barbara P. Kelkhoff
Manager
, Regulatory
Affairs
Chamberlain GmbH
Alfred-Nobel-Str. 4
D-66793 Saarwellingen
May 2015
16
Service parts / Warranty
Your statutory rights are not affected by this manufacturer's warranty.
Please see www.liftmaster.eu/warranty for terms of warranty.
__
18. Description of LEDs
LED1
• Flashes briefly: A radio signal is received. Once the remote control
is programmed it opens and closes the opener.
• Is constantly on for approx. 10 seconds: An additional remote can be
programmed or all remotes will be deleted.
LED2
• Is constantly on: as long as the opener runs.
• Flashes: opener is in programming mode, „OPEN” position has
already been programmed and opener is ready for position
„CLOSED“.
LED3
• Flashes: opener is in programming mode and ready for „OPEN“
position
17. The running path cannot be programmed, is de-programmed
or is changing slowly:
• The programmed running path is too short. Programme a longer path
for testing purposes.
• A small plastic knob is factory-mounted on the chain that is running in
the rail. During the travel of the opener this little button must press
the small switch located on the drive head. If the path is too short
or the button was torn down by incorrect installation, it has to be fixed
again. If the small switch is not pressed, the programming of the
opener is not possible.
• A mechanical fault at the door due to deflected joints or the chain ten-
sion on the drive is too loose.
Regulatory
