en 13/13
Service parts / Warranty
Please refer to www.chamberlain.eu or contact your local dealer.
Also refer to the available Warranty Book.
36
37
Declaration of conformity
Specifications
Input Voltage...................220-240 VAC, 50/60 Hz
Max. Pull Force ..............800 N (ML800EV), 1000 N (ML1000EV)
Standby Power
(door fully closed)...........0.8 W
Motor
Type................................DC gearmotor permanent lubrication
Noise level......................54dB
Drive Mechanism............Belt
Length of Travel..............Adjustable
Opening speed, up to ....200 mm/s
Lamp...............................On when door starts, off 2-1/2 minutes
after stop.
Door Linkage ..................Adjustable door arm. Pull cord trolley release.
Safety
Personal .........................Push button and automatic stop in down
direction. Push button and automatic stop in
up direction.
Electronic........................Automatic force adjustment
Electrical .........................Transformer overload protector and low
voltage push button wiring.
Limit Device ....................Mechanical RPM/Passpoint detector.
Limit Adjustment .............Electronic
Soft-Start / Soft-Stop........all
Dimensions
Length (Overall)...............3183 mm
Headroom Required .......min. 35 mm
Hanging Weight ..............~12 kg
Receiver
Memory Registers ..........180
Operating Frequency.......6-Band (433 MHz / 868 MHz)
The declaration of conformity is included in this operating
manual.
One piece doors
max. width (mm)
max. height (mm)
max. weight (kg)
Sectional doors
max. width (mm)
max. height (mm)
max. weight (kg)
Door dimensions und -weight
ML800EV ML1000EV
ML800EV ML1000EV
Max. power of the
remote control.................. < 5 mW
5000
2250
110
5000
2250
110
5000
2690
110
5500
2690
130
