7
Option 1: External Wire Installation (continued)
03
Insert the Power Module into the Keypad.
04
Place the new Back Cover over the Power
Module. Set the Keypad aside.
POWER
MODULE
05
Locate the outlet you wish to use (do not
plug in). Lay out the wire along intended
path to check length.
06
Hold the new Swivel Mount up to the wall
and mark the top and bottom holes.
25 ft.
NOTE: If you’re replacing an existing mount,
skipsteps6and 7.
