8
Option 1: External Wire Installation (continued)
07
Use a 3/32 in. drill bit to drill the top and
bottom holes in the wall.
08
Thread the wire from the Wall Side to the
front of the mount as shown below.
09
Make sure the wire is directed through one
of the channels in the back, depending on
if you will route the wire to the right or left.
10
Carefully screw the mount into the wall,
making sure not to pinch any wires.
NOTE: If drilling into brick, stucco, or concrete,
use the included wall anchors and a 1/4 in.
masonry bit. Wall anchors are placed in the hole,
and then the screws are screwed in. See step 10.
To Next Page
