Champion Power Equipment 100310 - Parts List

100310 - 3000 PSI PRESSURE WASHER
SPECIFICATIONS
22
# Part Number Description Qty.
1 26.111
Engine
1
2 2.14.001
Key, SQ
4.78 x 4.78 x 40
1
3 2.08.010 Bolt 5/16-24 x 22 4
4 1.93.08 Lock Washer Ø8 4
5 252.251003.00 Inlet Filter Gasket 1
6 254.251000.01 Pump Body 1
7 256.250100.01
Detergent Hose,
47.2 in.
2
8 254.252200.00 Wand 1
9 254.252100.00.2 Handle, Gun 1
10 1.5783.0645 Bolt M6 x 45 2
11 254.200012.05.2 Trigger Gun Holder 1
12 1.6177.1.06 Lock Nut M6, Flange 12
13 254.252300.05
Nozzle "Detergent",
65400
1
14 254.252300.09 Nozzle "40", 40028 1
15 254.252300.08 Nozzle "25", 25028 1
16 254.252300.06 Nozzle "0", 00028 1
17 252.201400.01 Sheath, Nozzle 4
18 1.5789.0615.1
Flange Bolt M6 x 15,
Black
7
19 254.200800.00.2 Decorative Sheet, Up 1
20 2.08.139 Bolt M6 x 35 2
21 254.200701.06.78 Handle, Frame 1
# Part Number Description Qty.
22 254.201600.00.78 Mounting Plate 1
23 1.5789.0615 Flange Bolt M6 x 15 6
24 1.5789.0608 Flange Bolt M6 x 8 1
25 254.200012.03.78 Hose Hanger 1
26 254.250100.00
High-Pressure Hose,
25 ft.
1
27 252.201300.00 Pin 2
28 254.201100.08.78 Frame 1
29 1.6182.10 Lock Nut M10 2
30 254.201701.03.48 12 in. Wheel, Yellow 2
31 2.08.007 Bolt M10 x 82 2
32 1.6177.1.08 Lock Nut M8, Flange 8
33 252.201200.00
Vibration Mount,
Engine
2
34 83.201400.01
Vibration Mount,
Support Leg
2
35 1.5789.0620 Flange Bolt M6 x 20 2
36 254.250203.01 Cap, Detergent Tank 2
37 254.250200.01 Detergent Tank, Left 1
38 254.250200.02 Detergent Tank, Right 1
39 254.200800.01.2
Decorative Sheet,
Down
1
Parts List
