INTRODUCTION
Congratulations on your purchase of a Champion Power Equipment winch.
CPE designs and builds winches to strict specifications and with proper use
and maintenance should bring you years of satisfying service.
WARNING - Read, study and follow all instructions before operating this
device. Failure to heed these instructions may result in personal injury and/or
property damage.
Your winch can develop tremendous pulling forces and if used unsafely or
improperly could result in property damage, serious injury or death.
Throughout this manual you will find the following symbols for caution, warning
and danger. Pay particular attention to the notes preceded by these symbols as
they are written for your safety. Ultimately, safe operation of this device rests
with you, the operator.
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. This notation is also used to alert
against unsafe practices.
Indicates a potentially hazardous situation which, if not avoided
could result in death or serious injury.
CAUTION

Table of Contents

Questions and Answers

  • S
    Scott MitchellAug 5, 2025
    How to troubleshoot a Champion Power Equipment Winches motor that won't turn on?
    • N
      nicole65Aug 5, 2025
      If the Champion Power Equipment Winches motor doesn't turn on, here's what to check: * **Switch Assembly:** Ensure the Switch Assembly is fully inserted into the connector. * **Battery Cables:** Tighten all nuts on cable connections to address any looseness. * **Solenoid:** Tap the solenoid to free contacts. Directly apply 12 volts to the coil terminals; a clicking sound indicates proper activation. If it’s defective, replace the Switch Assembly. * **Motor:** With the switch pressed, check for voltage at the armature port. If voltage is present, the motor may be defective and needs replacement. * **Water:** If water has entered the motor, allow it to drain and dry completely. Run the motor in short bursts without a load until it's fully dry.
  • H
    hunterkimAug 11, 2025
    Why is my Champion Power Equipment Winches motor running slowly?
    • V
      Veronica PattonAug 11, 2025
      If your Champion Power Equipment Winches motor runs slowly or lacks its usual power, there are a couple of things you can check: * **Current/Voltage:** The battery might be weak. Try recharging it or running the winch while the vehicle's motor is running. * **Battery Cable Connections:** Look for loose or corroded connections. Clean, tighten, or replace them as needed.
  • R
    robertmasonAug 17, 2025
    What to do if Champion Power Equipment C20049 Winches motor runs in one direction only?
    • S
      Sandra BuckAug 17, 2025
      If your Champion Power Equipment Winches motor only runs in one direction, it could be due to: * **Solenoid:** A defective or stuck solenoid. Try tapping it to loosen the contacts. * **Switch Assembly:** A defective Switch Assembly, which would need replacement.
  • L
    luisbrooksAug 23, 2025
    Why is my Champion Power Equipment C20049 motor overheating?
    • H
      Haley BartonAug 23, 2025
      If the Champion Power Equipment Winches motor is overheating, it may be running for too long. Allow the winch to cool down periodically.
  • P
    Phillip SmithAug 28, 2025
    What to do if Champion Power Equipment C20049 Winches motor runs but cable drum does not turn?
    • C
      Carla SmithAug 28, 2025
      If the Champion Power Equipment Winches motor runs but the cable drum doesn't turn, the cam ring (clutch) may not be engaged. Move the cam ring to the “In” position. If the problem persists, a qualified technician needs to check and repair it.

Summary

INTRODUCTION

INCLUDED WITH YOUR WINCH

WINCH ACCESSORIES YOU WILL NEED

Lists essential accessories not included with the winch for proper operation.

Winch ASSEMBLY AND MOUNTING

SAFETY PRECAUTIONS

GENERAL TIPS FOR SAFE OPERATION

RIGGING TECHNIQUES

Self Recovery

Techniques for recovering a vehicle using the winch in various scenarios.

WINCHING TECHNIQUES A-Z

MAINTAINNENCE

REPLACING THE WIRE ROPE

Steps to remove and install new wire rope on the winch drum.

TROUBLE SHOOTING

WINCH ASSEMBLY DRAWING

WINCH PARTS LIST

Warranty

Warranty Qualifications

Requirements for registering and validating the winch warranty coverage.

Repair;Replacement Warranty

Details the period and conditions for component repair or replacement.

Warranty Exclusions

Lists specific conditions and components not covered by the warranty.

Contact Information

Provides address and phone numbers for customer and technical support.

Champion Power Equipment C20049 Specifications

General IconGeneral
ModelC20049
TypeElectric Winch
Rated Line Pull2000 lbs
Gear Ratio153:1
Cable Length50 ft
Cable TypeSteel
Rope Capacity50 ft
FairleadRoller
Remote ControlYes
Motor12V DC
Cable Diameter5/32 in
