Champion M2 Series Installation Guide

5-3/4"
[145]
Min.
Clearance
4-11/16"
[119]
5"
[128]
90-15/16"
[2309]
27"
[686]
68-15/16"
[1752]
3-9/16"
[91]
8-9/16"
[217]
6-1/16"
[154]
4-13/16"
[122]
6-7/8"
[175]
18-7/16"
[469]
5-3/4"
[146]
25-3/8"
[645]
Inside Table
Flange
26-7/8"
[683]
8-5/16"
[212]
33-15/16"
[862]
Rinse Aid
Injection
1/8" NPT
Detergent
Injection
7/8" DIA
Detergent
Probe
7/8" DIA
6-1/4"
[159]
4-7/16"
[112]
19-1/2"
[496]
11-5/16"
[288]
26-1/8"
[664]
7-1/4"
[184]
31-5/8"
[804]
60"
[1524]
Due to an ongoing value analysis program at Champion,
specifications contained in this catalog are subject to
change without notice.
Champion Industries, Inc.,
3765 Champion Blvd., NC 27105
336/661-1556 • Fax: 336/661-1979
ChampionIndustries.com
DH6000T High Temperature
Hood-type Dishwashing Machine
DH6000T
Shipping weight crated: 300 lbs.
Dimensions shown in inches and [mm]
Front ViewSide
View
Side
View
Machine & Built-in Booster (Standard)
Voltage
Rated
Amps
Minimum Supply
Circuit Ampacity
Maximum
Overcurrent
Protective Device
208-240/60/1 77-68 100 100
208-240/60/3 46-41 60 60
480/60/3 20 30 30
Machine Only
(two point electrical connection or no built-in booster)
Voltage
Rated
Amps
Minimum
Supply Circuit
Ampacity
Maximum
Overcurrent
Protective Device
208-240/60/1 38-34 50 50
208-240/60/3 25-23 30 30
480/60/3 11 15 15
Booster Only (two point electrical connection)
Voltage
Rated
Amps
Minimum
Supply Circuit
Ampacity
Maximum
Overcurrent
Protective Device
208-240/60/1 39-34 50 50
208-240/60/3 21-18 25 25
480/60/3 9 15 15
SPECIFICATIONS
Capacities
Racks per hr. (NSF rated) 60
Wash tank (gal.) 10
Motor horsepower 2 HP
Water consumption
Gal. per hr. (max. use) 39
Gal. per rack 0.73
Temperature °F
Wash 150
Rinse 180
Heating
Tank heat, electric 5.2 kW
Electric Booster 7.5 kW
Dish-
washer
Mode
Pot &
Pan
Mode
Selectable cycle
times in minutes
1 246
Time cycles in seconds
Wash 36 94 214 334
Rinse 8 10 10 10
Sanitary Dwell 16 16 16 16
Total 60 120 240 360
Warning: Plumbing, electrical connections should be
made by qualified personnel who will observe all the
applicable plumbing, sanitary and safety codes and the
National Electrical Code.
Note: Optional Drain Tempering: 1/2” NPT cold water
connection required. 1/2” NPT drain connection from back flow
preventer to house drain. (FIELD INSTALLED and PLUMBED).
UTILITIES
1 Electrical Machine Connection
(See Electrical Box)
2 Hot Water 3/4" NPT Hot Water 110° - 140°F
20-22 PSI Flow Pressure
3 Drain 1.5" OD Connection; 15 GPM Max
Flow (Drain water tempering height 5")
4 Drain Water Tempering 1/2" Cold water
line with customer supplied cut-off valve
(optional)
5 Integrated Detergent System Detergent
bottle supply connections (optional)
Note: Water Hammer Arrestor (meeting ASSE-1010 standard or equivalent)
to be supplied (by others) in common water supply line at service connection.
Detergent
Injection
7/8" Dia
Detergent
Probe
7/8" Dia
Rinse Aid
Injection
1/8" NPT
Rinse
Pressure
Gauge
8-5/16"
[212]
33-5/8"
[853]
8-9/16"
[217]
6-1/4"
[159]
4-7/16"
[112]
19-1/2"
[496]
34-1/8"
[866]
26-7/8"
[683]
6-1/16"
[154]
25-3/8"
[645]
Inside Table
Flange
5-3/4"
[146]
4-13/16"
[122]
6-7/8"
[175]
18-7/16"
[469]
6" [152]
to Inside
Tank Wall
8-1/8" [207]
to Rack
Guide
64-5/16"
[1634]
68"
[1727]
48-7/8"
[1242]
7-1/4"
[184]
31-5/8"
[804]
4-11/16"
[119]
5-3/4"
[145]
Min
Clearance
15-5/16"
[389]
3-1/16"
[78]
3-9/16"
[91]
11-5/16"
[288]
Plan View
Corner Table
Configuration
Detergent
Injection
7/8" Dia
Detergent
Probe
7/8" Dia
Rinse Aid
Injection
1/8" NPT
Rinse
Pressure
Gauge
8-5/16"
[212]
33-5/8"
[853]
8-9/16"
[217]
6-1/4"
[159]
4-7/16"
[112]
19-1/2"
[496]
34-1/8"
[866]
26-7/8"
[683]
6-1/16"
[154]
25-3/8"
[645]
Inside Table
Flange
5-3/4"
[146]
4-13/16"
[122]
6-7/8"
[175]
18-7/16"
[469]
6" [152]
to Inside
Tank Wall
8-1/8" [207]
to Rack
Guide
64-5/16"
[1634]
68"
[1727]
48-7/8"
[1242]
7-1/4"
[184]
31-5/8"
[804]
4-11/16"
[119]
5-3/4"
[145]
Min
Clearance
15-5/16"
[389]
3-1/16"
[78]
3-9/16"
[91]
11-5/16"
[288]
Typical Table Construction
[762]
30"
1-1/2" [32] Roll
1-1/8"
[29]
7-1/4" [184]
21-3/8"
[543]
69-3/4"
[1770]
29-1/2"
[749]
4-3/8"
[112]
14-1/8"
[359]
19-5/8"
[500]
26-1/8"
[663]
8-3/4"
[224]
60-1/8"
[1526]
37-7/8"
[963]
33-3/4"
[857]
8"
[203]
6"
[152]
4-3/4"
[122]
8-3/4"
[221]
17"
[432]
8-7/8"
[225]
31"
[787]
34-1/8"
[867]
3-7/8"
[97]
41-3/8"
[1052]
18-1/8"
[549]
77-1/4"
[1963]
Hood
Up
17"
[431]
Clearance
7-5/8"
[192]
From
Wall
20-1/8"
[511]
INSIDE TRACKS
5-1/8"
[129]
3/8"
[9]
30"
[764]
Table
Typ
30"
[762]
26-1/2"
[673]
21-3/8"
[543]
1-1/2"
[38]
25-1/4"
[641]
Between
Tables
20-1/8"
[511]
8-3/8"
[214]
From Wall
INSIDE TRACKS
Specification Sheet
