Thr
ee ways to
REGISTER YOUR PRODUCT and
ACTIV
A
TE YOUR W
ARRANTY
.
•
Use your mobile device and connect to the website
www
.championindustries.com to r
egister your product.
•
Scan the UPC code http://champDW
.us located on the fr
ont of the
panel of the machine.
•
Complete the fax form on the next page and fax to 1-800 661-1660.
4:34 PM
44%
2
4
Table of Contents
Limited Warranty
6
Table of Contents
7
Specification Sheets
8
Installation Codes and Safety Symbols
16
Installation
16
Receiving and Placement
17
Dish Table Connections
18
Corner Operation - Corner Splash Shield
19
Corner Operation - Track Conversion
20
VHR Cold Water Connection-DH6000-VHR, DH6000T-VHR
21
Standard Hot Water Connection - DH6000, DH6000T
21
Drain Connection
22
Optional Drain Water Tempering Kit
23
Electrical Connections - Single and Three Phase
24
Single and Two Point Power Connections
25
Converting 3-Phase to 1-Phase Operation
26
Optional Champion Built-In Detergent and Rinse-Aid Dispensing System
27
Program the Chemical Dispensing System
28
Detergent Concentration Graphs
30
Delime Programming
32
Detergent Probe/Signal for Chemical Dispensing Systems by Others
34
Rinse-Aid Injector/Signal for Chemical Dispensing Systems by Others
35
Shortening a Chemical Pick-Up Hose Supplied by Others
36
Ventilation (Vent Fan Control)
38
APPENDIX A: DH6000T Corner Splash Shield Kit, P/N 901104
40
APPENDIX B: Kit P/N 901168, 1 to 2-Point Electrical Connection Conversion
43
APPENDIX C: Manually Operating the Drain Valve
46
