Champion PRO - Front Panel

7. Configuring through a web browser
Champion PRO GNSS Receiver User Guide Page 7
1. Power
Red
Power on – on
Battery has less than 30% remained – flash
2. Satellites
Green
Satellites found – flash every second
3. Corrections
Yellow
Green
Base is transmitting the corrections – flash every
second
Rover is receiving the corrections – flash every
second
Rover is in RTK float status – flash
Rover is in RTK fixed status – on
4. Wi-Fi
Orange
Wi-Fi on – on
Wi-Fi off – off
5. File recording
Yellow
Static data is logging – flash according to static
sample interval
Front panel
