www.chamsys.co.uk MagicQ Console Quick Start Manual
26 of 34
Hints for Operators used to other consoles
Users familiar with Hog II consoles
Choose “Hog II Warp Mode” or “Theatre Tracking Mode”
Feature MagicQ Hog II
Universes 18 4 (7 in overdrive)
Channels 9216 2048 (3584 in overdrive)
Alternate functions SHIFT PIG
Playback select SEL (S) CHOOSE (C)
Include for editing INC LOAD
Position control Position button Position button
Colour control Colour button Colour button
Beam control Beam button Beam button
Programmer Prog button Prog button
Naming items Enter text followed by enter SET, enter text followed by enter
Clear programmer Clear button Clear button
Release playback Select playback (S) then Release Release
Release all SHIFT RELEASE PIG RELEASE
Close all windows SHIFT CLOSE PIG CLOSE
Record Options SHIFT RECORD RECORD
Active Hold SET + soft button of attribute Active
Knockout Hold REMOVE + soft button of
attribute
Knockout
Common Problems for Hog II users
Keypad won’t select heads in Normal and Theatre modes
On MagicQ it is possible to edit the on screen windows directly using the keypad without pressing SET, just like you
would do with a spreadsheet on a computer. This means that unlike the Hog the keypad does not support direct
entering of head numbers to select heads – instead to select heads from the keypad you must add @@ after the head
numbers, e.g.
1 THRU 4 @ @
Note it is possible to force selection of heads from the keypad, but this in turns means that you have to press SET to
edit data in windows and restricts the live features of the console. If you want this option then set the “Keypad always
selects head” option in Setup.
