ASSEMBLY / ASSEMBLAGE / ASAMBLEA
CHARBROIL.COM
Page 33
PARTS LIST
Key Qty Description
1 1 TOP LID
2 1 TEMPERATURE GAUGE
3 1 BEZEL, F/ TEMP GAUGE
4 1 LOGO PLATE
5 1 HANDLE, TOP LID
6 1 HARDWARE F/ TOP LID ASSEMBLY
7 4 RUBBER BUMPER, W/ HOLE, F/ TOP LID
8 1 FIREBOX
9 1 HOSE VALVE REGULATOR
10 3 MAIN BURNER
11 1 ELECTRODE SET, F/ MAIN BURNER, 500MM WIRE
12 2 CARRYOVER TUBE
13 1 MAIN CONTROL PANEL
14 4 CONTROL KNOB
15 4 BEZEL F/ CONTROL KNOB
16 1 MATCH HOLDER
17 1 SWINGAWAY RACK
18 3 HEAT TENT
19 3 COOKING GRATE
20 1 CART SIDE PANEL, LEFT
21 2 WHEEL
22 1 AXLE
23 2 LEG CAP
24 2 END CAP
25 1 RIGHT SIDE SHELF
26 1 FASCIA, F/ RIGHT SHELF
27 1 SIDEBURNER SHELF
28 1 LID, F/ SIDEBURNER
29 1 DRIP PAN, F/ SIDEBURNER
30 1 FASCIA, UPPER, F/ SIDEBURNER SHELF
31 1 FASCIA, LOWER, F/ SIDEBURNER SHELF
32 1 SIDEBURNER
33 1 ELECTRODE, F/ SIDEBURNER
34 2 FRONT PANEL
35 2 REAR CART BRACE
Key Qty Description
36 1 CART SIDE PANEL, RIGHT
37 1 ELECTRONIC IGNITION MODULE
38 1 BUTTON, F/ ELECTRONIC IGNITION MODULE
39 1 IGNITOR WIRE, F/ SIDEBURNER
40 1 GRATE, F/ SIDEBURNER
41 1 GREASE CUP
42 1 GREASE CLIP
43 1 TANK EXCLUSION, WIRE
44 1 TANK RETAINER, WIRE
45 1 HEAT SHIELD, F/ SWITCH MODULE
46 3 BURNER BRACE
47 1 HEAT SHIELD, F/ TANK, FIREBOX
NOT Pictured
… 1 PRODUCT GUIDE, ENGLISH, FRENCH, SPANISH
… 1 HARDWARE PACK
… 1 IR CLEANING TOOL
… 1 VENTURI CLIP F/ SB
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your
particular grill model. However, the method of assembly remains the same.
