PARTS LIST AND TOOLS REQUIRED
Pliars and 7/16" nut driver
12 pcs.
2 pcs.
NO RETURNS ON
USED GRILLS
Copyright ©
STOP! CALL FIRST! DO NOT RETURN PRODUCT TO STORE.
CALL (912) 638-4724 This product has been built to the highest quality standards.
Call us should you have any questions not addressed in these instructions, or for service information.
P
R
O
F
E
S
S
I
O
N
A
L
G
R
I
L
L
S
&
S
M
O
K
E
R
S
Note: Hardware bag may
contain extras.
HARDWARE
USED
WITH YOUR
CHAR-GRILLER
(Tools Not Included)
Hex Nut
1
/4"
29 pcs.
Lock
Washer
3 pcs.
1
/4"
Washer
2 pcs.
Push on Wheel Cap
2 Pcs. for Wheels
3
/4"
Hex Bolt
9 pcs.
1
/2"
Hex Bolt
4 pcs.
1
3
/4"
Hex
Bolt
Hair
Cotter Pin
4 pcs.
Damper Circle
(Not to scale) 1 pc.
2"
Hex
Bolt
PARTS……....……….DESCRIPTION
1…...........EASY DUMP FIRE GRATE
3………...….......COOKING GRATES
1……….......…………...GRILL BODY
1………......…………..HEAT GAUGE
2………........…………...HINGE PINS
2………...…......HAIR COTTER PINS
1……..........
WOOD FRONT HANDLE
2………......……......3/4" HEX BOLTS
2……....….…….....LOCK WASHERS
2……......……..……..1/4" HEX NUTS
1…….......
SMOKESTACK & DAMPER
2….....……..…….....3/4" HEX BOLTS
2……......…………....1/4" HEX NUTS
1……..…….ACORN NUT & SPRING
2…….......….………...
LEGS (SHORT)
2……….........………....
LEGS (LONG)
4…..…….....……..1 3/4" HEX BOLTS
4……….....……….....1/4" HEX NUTS
PARTS…………..............DESCRIPTION
1……………..........…..WARMING RACK
2………………........…….2" HEX BOLTS
2………………........…..3/4" HEX BOLTS
4…………….........……...1/4" HEX NUTS
1…………..............….DAMPER CIRCLE
1………..…........………..3/4" HEX BOLT
2…………........……1/4" FLAT WASHER
1………….......…………LOCK WASHER
1……..……........…………1/4" HEX NUT
PARTS……….....…..……..DESCRIPTION
2…..………..........…………..……WHEELS
1…..…...........…………………..…...
.. AXLE
2…...…....…
......... PUSH ON WHEEL CAP
2...............................HAIR COTTER PINS
2…........
... HANGERS (FOR FIRE GRATE)
2……...........…………………
LEG BRACES
8…….....…. .... 1 3/4" HEX BOLTS & NUTS
1……..........…………………
. SIDE SHELF
4…….........…………….. .. 1/2" HEX BOLTS
4……........………..………1/4" HEX NUTS
1……….......…….CONDEMENT BASKET
2………........……………
3/4" HEX BOLTS
2………..........…………………HEX NUTS
-2-
2 pcs.
Hinge Pin
