7 Owner’s manual: model 82300 portable outdoor heater
Step 2–Attach Top Wire Guard
Line up 4 prongs on Wire Guard Bottom with 4 holes on Emitter Bottom,
and Insert.
Note: It may be necessary to adjust the prongs slightly to line them up
with the holes.
Step 3–Attach Dome to Emitter
Line up three studs in Emitter with holes in Dome. Slide Dome carefully
over studs, clamping Top Wire Guard securely in place.
Note: It may be necessary to adjust prongs of the Top Wire Guard
slightly to provide a secure fit.
Install (3) Nuts on studs and tighten with 7/16” wrench.
Do not over tighten.
Step 4–Attach Dome Cap
Lay Dome Cap on dome covering 3 Nuts and line up center holes.
Insert threaded end of Finial through cap and screw into center of dome
until secure.
