VI
Model SS-2 220-240 VOLT – (Low Water)
Cat. No. – 2307 w/packs
Cat. No. – 2309 w/o packs
Key* Part Description Part No.
1 Element, Heating, 240V~ CE 22245
4 Thermostat, Hydraulic 10631
3 Lamp, Pilot, Green 22146
11 Cord Set (Country Specific) See page 13
26 Switch 23406
28 Rack 22259
39 Hose, Nylon 5/8 x 4' Coupled M-F 21635
7 Caster, 3 inch 21259
21 Handle, M/SS, Lid, Finished 20513
23 Handle, Side, Common (2) 20237
34 Lid, Assembly With Handle 22219
9 Cover, Junction Box, M-2, 220-240 Volt 22087
29 Drain, Copper M-2 Part A #25010 21286
5 Bracket, Bulb Thermostat, S/A (Lo-Water) (2)** 21023
35 Water Thief 21882
Spacer, Thermostat (Lo-Water) (2) 72393
Thermostat, (Lo-Water)*** 20548
15 Lamp, Red, Indicator (Lo-Water) 22147
14 Fuse, 6.3 Amp. (2) 71772
Fuse Holder (2) 72734
Receptacle, Power 8843-FSG-W-40-60 74723
27 Harness Wiring 61579
31 Tank, Replacement with Drain 23372
18 Insert, For neck Contour Packs 21053
Thermostat, LM5-2505 23393
20 Lid, Rod Nuts (2) 21737
22 Lid, Rod 22231
29 Valve, Ball 21085
Fit Bib, SS-2, M-2, M-4 23392
* pages 6 and 7
** Used to hold the Hydraulic Thermostat and Overtemp Thermostat to the
Heating element.
*** Includes Gasket Thermostat, Nut 1/2-20 Brass, and Overtemp Thermostat.
Hydrocollator
®
Heating Units
REPLACEMENT PARTS
