Chattanooga Intelect HPL15 - Page 2

2
EN
Images
B
C
D
A
E
G
F
H I
N L
J M K
A. Handpiece
B. 7” Touch screen display
C. Emergency stop button
D. Multi-function knob
E. Calibration socket
F. Label showing laser data
G. Product identification label
H. Main switch
I. 2x2AT Fuses
J. 100-240 V ~ 50/60 Hz socket
K. Cooling fan
L. Interlock
M. Footswitch socket
N. Interlock for patient button
(Optional)
