Chelino REVO - Securing the Child with the Harness

Step1.Put the two metal sections of the buckle
connectors together.
Step2.Slot the two buckle connectors into the slot in
the top of the buckle until they“click” into place.
Step3.Check the harness is correctly locked by
pulling the shoulder straps upwards.
To release the harness, press the red button on the buckle downwards.
Using the buckle
click
9
10
Step1. The shoulder straps are slackened by
pressing the lever (under the car seat cover)
on the front of the car seat.
Step2.Press down on the label marked“Press”
as you grip the two should straps with your
other hand. Pull the shoulder straps towards
you to loosen it.
Firstly, adjust the shoulder belts height (see
point4.1), proceed as follows:
Step1. Loosen the harness(see point4.3), open
the buckle(see point4.4.1), and place them
down sideways.
Step2. Seat your child in the child car seat.
Place both shoulder belts over your child’s
shoulders. Fasten the buckle (see point 4.4.1).
Step3.Pull the shoulder straps upwards to
remove the slack from the lap sections of the
harness then pull the adjuster strap until the
harness is fully tightened ( see left picture).
PRESSPRESS
Loosening the shoulder straps
PRESSPRESS
Securing the child with the
harness
The harness should be adjusted as tightly as possible without causing discomfort to
your child.A loose harness can be dangerous. Check the harness adjustment and
tighten each time the child is placed in the seat. Ensure that any lap strap is worn
low down, so that the pelvis is firmly engaged, the belt is not twisted.
