Removal of the harness
11
12
USAGE FOR THE AGE GROUP II /III
Step1. Loosening the harness(see point4.), turn the seat to the back
Step2.Slide both of the harness straps off the harness connector
Step3. Slide the belt of the chest pads off the chest pad connector
Step4.Pull the strap till the steel pole gets out of the slot Now you can remove the
belts as well as the tongue in an upwards direction.
Installation of the harness is carried out in reverse order to removal.
Keep harness with all parts in a safe place, to use in the future.
The harness system must be removed from the seat when used for these age group
II,III, which means from 15kg to 36kg. Only the 3-point vehicle belt system can be
used to buckle up the child car seat.
belt lock system includes red belt lock, belt, connector Install the belt lock system
Pull the belt one side fixed connector through one top hole of the base(see picture1) ,
slide the belt into the hook of the connector (see picture 2,3,4,5).
Releasing the belt is carried out in reverse order to removal. Note: For group II,the
bottom belt of belt lock system is fixed into the top hole which is far away from the car
seat buckle. For group III,the bottom belt of belt lock system is fixed into the top hole
which is near to the car seat buckle.
Adjust the belt length as the picture,just make belt lie on child shoulder ,please see the
following picture .
adiust
lock unlock
Install and adjust the belt lock system
