Securing the child car seat with vehicle’s belt with belt
lock for group II from 3 to 7years (15-25kg)
IMPORTANT: Before fitting the seat, remove the shoulder straps, crotch strap and then
fit the seat belt lock only in upper 2 row slots as shown.
click
STEP.1
STEP.2
STEP.3 STEP.4 STEP.5
Step1. Thread the belt lock (with belt) into the proper slot which is nearest to the top
of child shoulder on the side of the car belt automatic roll-up device. Pull the belt lock
from back side of child seat to its face side.
Step2. Place the child safety seat on the vehicle’s seat ensuring it is firmly pressed
against the car seat’s backrest. Seat your child in the child car seat.
Step3. Pull out the 3-point vehicle belt and place the lap belt on the opposite side of
the buckle under the arm rest.(Make sure that the diagonal belt and the lap belt on the
buckle side are under the armrest). And allow it to the buckle in place. You will
hear “click”.
Step4. Place the diagonal belt goes through the belt lock . Make sure that the belt is
not twisted. Note :choose the hole nearest to child shoulder to guide the belt lock.
Step5.Tighten the adult belts and the diagonal shoulder belt in the direction of the
automatic roll-up as possible. Pull the strap in the front of child safety seat to adjust
anger of the diagonal shoulder belt.All the belts should be adjusted as tightly as
possible without causing discomfort to your child.Main load point must be up car seat
buckle.The satisfactory position of the adult safety-belt buckle relative to the child car
seat is as the following picture( Fig. 6).You can contact us if in doubt about this point.
The car seat must be used vehicle’s 3-point belt system for children of the age groups II
(15kg-36kg). The harness system must be removed from the seat (see point 5.1).
Securing the child car seat with backrest and belt lock (group II）
