Chelino REVO - Securing Group III with Vehicle Belt Lock; Securing Group III with Belt Lock

click
STEP.1
STEP.2
STEP.3 STEP.4 STEP.5
IMPORTANT: Before fitting the seat, remove the shoulder straps, crotch strap and
backrest.
Step1. Place the child safety seat on the vehicle’s seat ensuring it is firmly pressed
against the car seat’s backrest. Seat your child in the child car seat.
Step 2. Place the child on the safety seat. Guide the belt lock (with belt) to child
shoulder which is near to car belt automatic roll-up device. Pull the belt lock from
back side of child to child’s face side.The strap lies on the middle of child’s shoulder.
Step3. Pull out the 3-point vehicle belt and place the lap belt on the opposite side of
the buckle under the arm rest.(Make sure that the diagonal belt and the lap belt on
the buckle side are under the armrest). And allow it to the buckle in place. You
will hear “click”.
Step4. Place the diagonal belt goes through the belt lock.Adjuse the length of the belt
and make sure the strap lies on the middle of shoulder.Don’t too close to neck and
shoulder side edge.Make sure that the belt is not twisted.
Step5.Tighten the adult belts and the diagonal shoulder belt in the direction of the
automatic roll-up as possible. Pull the strap in the front of child safety seat to adjust
anger of the diagonal shoulder belt.All the belts should be adjusted as tightly as
possible without causing discomfort to your child.
Main load point must be up car seat buckle.The satisfactory position of the adult
safety-belt buckle relative to the child car seat is as the following picture.You can
contact us if in doubt about this point.
15
16
Securing the child car seat with vechile’s belt with
belt lock for group III from 7 to 11 years (22-36kg)
