16-Port 6Gbps Mini-SAS Expander Backplane User’s Manual
http://www.chenbro.com
5
Hardware Specification
Backplane P/N: 80H10331605A0
Specification
Host Interface
1 x Mini-SAS Connector (SFF-8087) to the RAID/HBA or MB via SAS expander
1 x Mini-SAS Connector (SFF-8087) to another enclosure for daisy-chain.
HDD Interface SATA-I, II, III or SAS-I, II HDDs
Hot-Swap Hard drives can be replaced during system on line
Display
LED indicates Hard Disk Drive status (Defined by Chenbro)
Power LED – Blue (When HDD is present)
Access LED –Green (When HDD is busy)
Error LED –Red (When HDD is error)
Cooling 4 x 4pin Fan connector
Power Connector
4 x Standard +5V and +12V 4-pin power connectors
2 x 4pin Power connectors for Slim FDD & ODD
Other Connectors
1 x PIN Header 2.0mm (2x5)
1 x PIN Header 2.54mm (1x4)
1 x PIN Header 2.54mm (2x3)
1 x 6-dip function switch
2 x 2-dip Power mute & power alarm
4 x 4-dip Fan connector
Dimension 422.5 (Width) x 112 (Height) x 2.4 (Thickness) mm
Material FR4 8 Layer
Accommodated Chassis
 RM31616
 RM31070
