Page 9
G746A PARTS LIST
*Not furnished with riveter. Must be
ordered separately if desired.
"No Substitutions.
"*Not sold separately
Note: Use Loctite® #271 or equivalent
when assembling items 1 and 1A.
ITEM NO. DESCRIPTION QTY.
845-016 SUB-ASSEMBLY, HEAD
845-019 SUB-ASSEMBLY, HEAD CYLINDER
1 845-018 CYLINDER, HEAD 1
1A 845B6 FITTING, NOSE 1
2 P-701 0-RING 2
3 P-998 RING, BACK-UP 1
4 845-017 PISTON, HEAD 1
5 P-304 RING, QUAD (.943, .737, .103) 1
6 P-106 RING, BACK-UP (.926, .750, .088) 1
7 P-848 0-RING (.941_801_070) 1
8 P-244 0-RING (1.066, .926, .070) 1
9 P-112 0-RING (.504, .364, .070) 1
10 701B4 CAP, HEAD CYLINDER 1
11 P-880 RING,RETAINING (NON-STANDARD) 1
12 703A13 FITTING, DEFLECTOR 1
13 530A16 DEFLECTOR, PIN 1
14 P-572 STAT-O-SEAL 1
15 P-573 SCREW, BUTTON HD. SOC. 10-32 x 1/4 1
704-086 SUB-ASSEMBLY, HANDLE
16 703A33 ASSEMBLY, TRIGGER (INCLUDES P-223) 1
17 P-223 10-RING 1
18 703A11 HANDLE 1
56 P-653 0-RING (.691, .551, .070) 4
19 700B96 SLEEVE, VALVE 1
20 700A67 SPRING 1
21 P-829" 0-RING, DISOGRIN (.504, .364, .070) 4
54
700A94 SUB-ASSEMBLY, VALVE SPOOL
22 700B95*"
.
SPOOL, VALVE
1
23 700A18"* FILTER 1
24
700A69*" SCREW, METERING 1
25 P-834" 0-RING, DISOGRIN (.816, .676, .070) 2
26 700A16 PLUG, VALVE • 1
27 700A17 MUFFLER 1
28 P-279 RING, RETAINING (INT. 0.906) 1
29 700-247 CYLINDER, POWER 1
30 P-833" 0-RING, DISOGRIN (1.068, .862, .103) 2
31 P-739 RING, BACK-UP (.624, .518, .053) 1
32 P-830** 0-RING, DISOGRIN (.629, .489, .070) 1
33 700-248 ROD, POWER PISTON 1
34 P-727 0-RING (1.318, 1.112, .103) 1
35 700893 PLUG, PACKING 1
36 P-838" 0-RING, DISOGRIN 2
37 P-115 RING, BACK-UP 2
38 P-731 RING,BACK-UP 2
39 P-730 RING, QUAD 1
55 700A115
SUB-ASSEMBLY, KIT, AIR PISTON
40 700A110 WASHER, AIR PISTON 1
41 700C106 PISTON, AIR 1
42 700A111 WASHER, AIR PISTON 1
43 P-737 NUT, CONELOK, 1/4-20 1
44
P-725 0-RING 1
45 700C112 BASE, HANDLE 1
46 P-735 RING, RETAINING 1
47 700D107 COVER, BASE 1
48 P-736 RING, RETAINING 1
49 P-27 SCREW, SOC. HD. CAP, 8-32 x 1/2 4
50 P-832" 0-RING, DISOGRIN 1
51 700A22 GASKET 1
52 P-948* HOSE, AIR 1
53 670A20* BAG, STEM CATCHER 1
To Next Page
