Chery QQ Service Manual 465 Engine Mechanical System
- 3 –
Chery Automobile Co., Ltd
Oil quantity 3.5L
Transmission oil
Base on local temperature; select GL-4、or GL-5 Transmission oil；
quantity：2.1 L
Suction filter Dry type
Spark F6RTC
Generator Silicon rectify generator
Start-mode Electric start-up
Cooling method Pump circulation water-cooling
Lubricating method Pressure and splash compound
1.2 Oil pump
3000rpm 294 - 539kpa
1.3 Specification of fastener
Application Specification
Engine Metric(N.m)
Pulley bolt 95 + (30°- 45°)
Stretching pulley accessories bolt 26±4
Camshaft bracket cover bolt 8±2
Camshaft timing pulley bolt 45±5
Connect rod bearing cap bolt
28～32
Coolant temperature sensor Max 20
Crankshaft main bearing cap bolt 43-48
Cylinder head bolt 55-60
Engine flywheel bolt 40-45
Exhaust manifold nut 18-23
Engine mounting bracket set bolt 25±2.5
Knock sensor bolt 15-25
Intake manifold nut 18-23
Oil filter 12-16
Oil pan bolt 4-5
Oil pan drain plug 20-25
Oil pressure sensor 12-15
Oxygen sensor 40-60
Oil pump bolt 8-10
Spark plug 20-30
Left overhang of connecting front frame
side member
50±5
Engine left overhang gasket of
connecting transmission
40±5
