Chery DA465Q-1A2/D User Manual

Chery QQ Service Manual 465 Engine Mechanical System
- 2 –
Chery Automobile Co., Ltd
CHAPTER 1 Technical Parameters of Engine
1 Specification
1.1 Technical specification
Model DA465Q-1A2/D
Mode
Four cylinders. Four stroke. Water-cooling. Inline.
.Breadthways. Overhead camshaft. EFI
Bore 65.5mm
Stroke 78mm
Pressure ratio 9. 0: 1
Displacement 1051m1
Nominal power
38.5kW（5200 r/min）[gross power]
MAX torque
83NZm（3000～3500r/min） [gross power]
MIX fuel consumption 275g/kwZh[gross power]
Nominal RPM 5200r/min
Idle speed 850±50r/min
Emissions
Idle speed CO≤0.5% HC≤100PPm DB11/044-1999
High idle speed
CO≤0.3% HC≤100PPm DB11/044-1999
Mode CO≤2.2 g/km HC+NO
X
≤0.5g/km EC 96
Strays GB 14023-2000
Steering Anticlockwise ( From opposite )
Spark advance angle
6°～7° [idle model]
Spark order
1－3－4－2
Oil pressure
0.294～0.539MPa（3.0～5.5kgf/cm
2
）3000r/min
Dimensions
length×width×height
Inclusive transmission 776×609×656.7mm
Not inclusive transmission 396×609×656.7mm
Weight Not inclusive transmission 98kg
Fuel 90#(RON90) or more GB19730-99 unleaded gasoline
Oil
Environmental temperature >－20 SF15W/40
<－20 SF5W/30
Coolant quantity 4.5L
