Training Center of After-Sales Department Chery International
10. External lighting system
152
3. Function description – Follow Me Home
Function description of external lighting
Front fog lamp
When following conditions are met, BCM will turn on front fog lamp (BCM
controls front fog lamp external relay via low-side drive):
① Ignition key at ON
② Parking lamp on
③ Front fog lamp switch turned on (latching switch)
When the front fog lamp is lit, BCM will send CAN signal Front Fog Light Sts=1
to body CAN.
Rear fog lamp
When following conditions are met, BCM will turn on rear fog lamp (BCM outputs
high voltage and internal relay inputs high voltage):
① Ignition key at ON
② Parking lamp on
③ Front fog lamp switch or low beam lamp turned on
④ Rear fog lamp switch turned on (rear fog lamp switch is inching switch)
When the rear fog lamp is lit, BCM will send CAN signal Rear Fog Light Sts=1
to body CAN.
