12. Instrument cluster
182
2. Function description
Driver side safety belt indicator
The driver side safety belt indicator signal comes from the driver side safety belt buckle (pin 19).
驾驶侧安全带开关
Parameter
Condition
Min
Typ
Max
Driver side safety belt switch
Pin19
驾驶侧安全带指示
低电平
ON
悬空
OFF
Low voltage
Open
Pin19
Driver side safety belt
indicator
