Chery Tiggo 5 T21 - TELEMATICS: Wireless Communication Description

Training Center of After-Sales Department Chery International
14. TELEMATICS system
221
T-BOX is connected with the serial port of the onboard navigation device, and the cell phone
Bluetooth is used as a channel to connect it to the TSP background
I. Description on wireless communication
Speed signal
Serial port
Audio
device
Bluetooth
module
Instrument
Radio
Power
amplifier
Panel 1
GPS
antenna
Steering wheel
button
Voice control
module
Structure
Screen
Picture/video
decoding
