Chery Tiggo 5 T21 - Safety Airbag System: General Description

Training Center of After-Sales Department Chery International
16. Safety airbag system
245
1. General description
The highest configuration for T21 is a 6-airbag
system.
Major components include:
Driver airbag
Passenger airbag
Driver safety belt pre-tensioner
Passenger side safety belt pre-tensioner
Front passenger sensor
Driver side safety belt switch
Passenger side safety belt switch
Airbag module
Spiral line
Airbag fault indicator lamp
