Chery TIGGO Service Manual

Service Manual for Chery·Tiggo(T11) Engine Section
5
Item
Standard Value
Usage Limit
Value
Secondary processing size of air-in valve
seating hole enlargement
0.30 O.S.
34.435－34.455
0.60 O.S.
34.735－34.755
Secondary processing size of air-out valve
seating hole enlargement
0.30 O.S.
31.935－31.955
0.60 O.S.
32.235－32.255
Remarks:
O.S.: Enlarged diameter
5. Tightening torque
Tightened Part
Torque (kgf .M)
Alternator, Ignition system
Water pump belt gear
Adjusting bolt
Locking bolt
Alternator bracket screw bolt
Alternator center axle nut
Crank belt gear
Ignition coil
Spark piston
Camshaft position sensor cylinder
Camshaft position sensor bracket
Camshaft position sensor
0.9
1.0
2.2
2.4
4.5
2.5
1.0
2.5
2.2
1.4
1.0
Timing Belt
Protruded screw bolt on timing belt cover
Tensioner wheel screw bolt
Tensioner arm screw bolt
Automatic tensioner screw bolt
Central belt wheel screw bolt
Tensioner bracket
Timing belt rear cover
Timing belt indicator
Engine oil pump belt gear
Screw bolt of crank belt gear
Tensioner “B”
Belt gear of balance axle
Screw bolt of camshaft belt gear
Belt gear of balance axle
1.1
4.9
2.2
2.4
3.6
4.9
1.1
0.9
5.5
12.0
1.9
4.6
9.0
4.6
Fuel System
Throttle
1.9
