Vehicle Care 10-7
Lifting From the Rear
The rear lifting points can be
accessed from the rear of the
vehicle, on either the driver's or
passenger's side.
1. Locate the rear lifting points (A),
according to the illustration
shown.
2. Be sure to place a block or pad
between the jack and the
vehicle.
3. Lift the vehicle with the jack,
making sure the jack spans at
least two of the crossmember
ribs (B).
For more information, see Doing
Your Own Service Work on
page 10‑8.
