5
SEATS
Front Seats
A. Seat Adjustment
Lift the bar under the front of the seat to
slide the seat forward or rearward.
B. Seat Height Adjustment
Turn the knob to raise or lower the seat.
C. Seatback Recline Adjustment
Lift the rear lever to recline or raise the
seatback.
Folding Rear Seats
1. Unbuckle the safety belts and return
them to their normal stowed position.
Note: When raising the seatback, insert the
safety belt latch plate into the hole on the side
trim (A) to ensure that the safety belt does not
cross the seatback locking mechanism.
2. Press both buttons on the rear head
restraint posts and pull up the head
restraint to remove it. Store the head
restraint inside the cargo net.
3. Slide the front seats forward.
4. Pull up on the front edge of the rear
seat cushion to release it. Tilt the seat
cushion forward.
5. Pull up the release knob on top of the
seatback (B). Fold the seatback forward.
See Seats and Restraints in your Owner Manual.
A
A
B
C
B
