Vehicle Care 10-25
Headlamps, Front Turn
Signal and Parking
Lamps
High/Low-Beam Headlamp
1. Connector Retaining Tab
2. Connector Release
3. Headlamp Bulb
To replace a headlamp bulb:
1. Open the hood. See Hood on
page 10-4.
2. Remove the connector
retaining tab (1).
3. Disconnect the wiring harness
connector from the bulb (3) by
pressing the connector
release (2) and pulling
straight back.
4. Remove the bulb (3) from the
headlamp assembly by turning
counterclockwise and pulling
straight back.
5. Install the new bulb in the
headlamp assembly by turning
clockwise.
6. Install the wiring harness
connector to the bulb. Be sure
the connector release (2) locks
into place.
7. Install the connector
retaining tab (1).
Front Turn Signal/Parking
Lamps
To replace a front turn signal bulb:
1. Open the hood. See Hood on
page 10-4.
2. Turn the bulb socket
counterclockwise and pull it out
of the lamp housing.
3. Pull the bulb straight out of the
bulb socket.
4. Install the new bulb into the
socket by pressing it in.
