Chevrolet Volt Owner Manual - 2012
Vehicle Care 10-37
Fuses Usage
F6
Body Control Module 5/
Retained Accessory
Power Relay Control/Right
Front Turn Signal Lamp/
Left Rear Stop and Turn
Signal Lamp/Right
Parking Lamps/Remote
PRNDL
F7
Body Control Module 6/
Map Lights/Courtesy
Lights/Back – up Lamp
F8
Body Control Module 7/
Left Front Turn Signal/
Right Rear Stop and
Turn Signal Lamp/Child
Security Lock Relay
Control
Fuses Usage
F9
Body Control Module 8/
Locks
F10
Data Link Connector,
Right (Secondary)
F11
Universal Garage Door
Opener (If Equipped)
F12 Blower Motor
F13 Empty
F14 Empty
F15 Empty
F16 Empty
F17 Empty
F18 Empty
Relays Usage
R1 Empty
R2 Empty
R3 Empty
R4 Child Lockout Relay
Diodes Usage
DIODE Empty
