Portable Gasoline Generator Operating Instructions
Description of Spare Parts
1514
Portable Gasoline Generator Operating Instructions
Description of Spare Parts
Sockets can be following patterns according to relevant regulations in
various areas:
Handrail
pipe
Oil drain
bolt
Foot
It is for measurement of engine s oil level Make sure
engine s oil level is between MIN and MAX in the dipstick of
oil filler cap before use Oil can be added after removing the
oil filler cap
'.
'
.
.
Unscrew this bolt when replacing the engine oil Drain out
the old engine oil and dispose of it properly according to
local laws aoviding damage to the environment
.
,.
It is to support the generator.
It is to make the generator realize safe grounding As to the
grounding method refer to the Page16 Make sure
unobstructed grounding before use
.
,.
.
After lifted up the pipe with self locking structure can be
used to move the generator
,,- ,
.
It is to start up the engine For the method refer to
thePage19
.,
.
It is to filter air and remove impurities in the air entering
cylinder As to the maintenance method refer to Page 29.,.
It is to control fuel s entering into the engine via fuel tank
During nonuse of generator leave the switch off
'.
,.
It is to control air flow into the cylinder when starting up the
engine As to the operating method refer to the Page 19.,.
It is to eliminate noise during equipment operation and
discharge high temperature exhaust of engine s combustion
Do not touch it to avoid scalding
,
'.
.
Oil filler
cap
Grounding
terminal
Starter
Grip
Air
cleaner
Fuel switch
Choke
valve
Muffler
When the rated current from one socket output more
than the socket , you shoud
to use simultaneously two or more sockets for power
output.
's nominal rated current
!
