1.2 DESCRIPTION OF THE COMPONENTS
Fig. A
A. Car seat – Seat
B. Car seat base
C. Isox connectors
D. Isox connector release button
E. Rigid connector fastening indicators
F. Top Tether
G. Top Tether Belt guide
H. Side Safety System
Fig. B
I. Headrest
J. Backrest
K. Headrest adjustment ring
L. Shoulder straps
M. Car seat belts
N. Buckle
O. Padded crotch strap
P. Recline lever
Q. Seat rotation lever
R. Belt adjustment strap
S. Belt adjustment button
T1 Upper belt guide Gr. 2/3
T2 Lower belt guide Gr. 2/3
U. Booster cushion
Fig. C
V. Isox connector eject strap
W. Top Tether door
X. Top Tether hook
Y. Top Tether adjustment button
Z. Tightness indicator
1.3 PRODUCT FEATURES
GROUP 0+, 1, 2 and 3
POSSIBLE INSTALLATION CONFIGURATIONS
Group Installation Type of
homologation
0+/1 Isox connec
-
tors + Top Tether
SEMI-UNIVERSAL
1 Isox connec
-
tors + Top Tether
UNIVERSAL
2/3 3-point seat belt UNIVERSAL
2/3 3-point belt +
Isox connec-
tors + Top Tether
SEMI-UNIVERSAL
IMPORTANT WARNING
HOW TO FIT THE CHILD CAR SEAT (with
ISOFIX SYSTEM) REAR-FACING: GR. 0+
(0-13 KG) and GR1 (9-18 KG).
This is an ISOFIX child restraint device. It is ap-
proved by the ECE R44/04 Standards for use in
vehicles equipped with ISOFIX safety anchor-
age systems.
In this conguration the child car seat is classi-
ed for SEMIUNIVERSAL use and is compati-
ble only with the seats of the vehicles indicated
in the "List of vehicles"
When using the ISOFIX system, it is essential to
read the vehicle manual before tting the child
car seat.
The child mass group and ISOFIX size class for
which the child restraint may be used in this
conguration are: GROUP 0+,GROUP 1, Class D.
In case of doubts, contact the manufacturer
of the restraint device or your dealer.
WARNING! When using ISOFIX, the attachment
of the lower anchorage systems is not sucient.
It is also essential to attach the “Top Tether” to
the anchorage point made available by the ve-
hicle manufacturer.
IMPORTANT WARNING
HOW TO FIT THE CHILD CAR SEAT (with ISO-
FIX SYSTEM) FRONT-FACING: Gr. 1 (9-18 kg)
This is an ISOFIX child restraint device. It is ap-
