Chicco Stack 1 User Manual

10 11
Seat Pad Assembly
6
6. Attach the Seat Pad and
thread the Harness Straps
through the corresponding slots
on the Seat Pad.
Attach both of the Shoulder
Pads to the Shoulder Straps as
shown.
Backrest Assembly
5A. To attach the Backrest to
the Seat Base insert one side of
the Backrest into the slot and
opening on the inside of the
Base.
You may need to squeeze the
recline handle on the back of
the Backrest when inserting
the Backrest into the slot and
opening.
5B. Pull the waist straps up out
of the way and then pull back
on the Backrest until the other
side snaps into place.
Make sure the Backrest is
attached securely by pulling up
on both sides of the Backrest.
SLOT
OPENING
5A
5B
WARNING
Avoid falls. Never use in high chair mode without backrest attached.

Chicco Stack 1 Specifications

General

Brand	Chicco
Model	Stack 1
Category	High Chair
Language	English
