Assembly
3
3. Place the Youth Stool Base
onto the floor with the
underside of the base facing up.
Position the Legs so that the
Front Legs (curved bar) are at
the front of the Youth Stool
Base.
Then Line up the Legs with the
grooves on the underside of the
Youth Stool Base and snap the
Legs into the Youth Stool Base.
The Legs cannot be removed
once installed. Make sure the
Legs are securely attached to
the Youth Stool Base by pulling
up on the Legs.
Backrest Assembly
4A. To attach the Backrest to
the Seat Base insert one side of
the Backrest into the slot and
opening on the inside of the
Base.
You may need to squeeze the
recline handle on the back of
the Backrest when inserting
the Backrest into the slot and
opening.
4B. Pull the waist straps up out
of the way and then pull back
on the Backrest until the other
side snaps into place.
Make sure the Backrest is
attached securely by pulling up
on both sides of the Backrest.
SLOT
OPENING
4A
4B
Avoid falls. Never use in high chair mode without backrest attached.
