CG Pro 6.00
Battery OK:5.45V
Open =200 > 245
Close =80 Exit
>Open =200 Read
Close =80 Exit
2/5
CHECKING THE BATTERY STATUS AND FIRMWARE
1. Press MENU to enter the programme menu.
2. Press UP or DOWN until you find: MISC SETTINGS
3. Press MENU to enter the miscellaneous mode.
4. Press the UP or DOWN button until you find the firmware/Battery condition display.
5. The battery status should read OK and tell you the voltage.
6. If the batteries need changing, the LED will remain permanently lit and a warning will be
displayed on the screen.
7.Should the LED be lit but nothing is visible on the LCD screen then change the batteries
immediately.
MOTION CONTROL
This allows the manual movement of the motor should this be necessary, for example if the
string became tangled and you need a way of powering the motor to facilitate this untangling.
Once you have finished using the manual control, press the MENU button to exit. You will then
be taken to the door setup menu as the door will need to be re-setup.
CLOCK 12/24HR
You may change the time format here by simply selecting your preference using the UP or
DOWN buttons.
SENSOR DELAY
This feature allows you to set a delay when using the ‘Light Sensor’. For example, if the door
was closing too early when using the ‘Light Sensor’, you could enable this feature and then,
when you select SENSOR in the CLOSE Settings, you now have the option of delaying the
closing by anything from 0 to 60 minutes. Simply press the UP/DOWN button to
increase/decrease the delay in 5-minute intervals. It is also possible to adjust the ‘Light
Sensor’ sensitivity in the LUX Adjustment Menu. To disable this feature, simply select NO in
the SENSOR DELAY menu.
EXTRA: MISC SETTINGS
USING THE LIGHT SENSOR
1. Press MENU to enter the programme menu.
2. Press UP or DOWN until you find: LUX ADJUSTMENT
3. Press MENU to enter the LUX adjustment mode.
4. Press UP or DOWN and navigate the “>” symbol to the READ option
5. Press MENU
6. This will take a quick snapshot of the current light level.
LIGHT SENSOR: ADJUSTING OPEN/CLOSE SENSOR VALUES
To adjust the OPEN or CLOSE trigger values, navigate the “>” symbol
to either OPEN or CLOSE. Press UP or DOWN button to select and MENU to
save.
Open: Min = 200 Max = 255 DEFAULT = 200
Close: Min = 0 Max = 199 DEFAULT = 80
NB: Darker is a lower number – Brighter is a higher number.
LIGHT SENSOR
Instructions
STANDARD/PRO
